Catalog › Parts manuals › TM 9-2320-280-24P › Accessory Items › Fig. 329

HMMWV 0 384-1 . . . . . . . . . . . . . . . . . . . . .1 Figure 419 . . . . . . . . . . . . . . . .0 TM 9-2320-280-24P · Fig. 329

Every part in figure 329 of TM 9-2320-280-24P (HMMWV M998 series (A0, A1 and A2) repair parts), group 2202 Accessory Items: 26 lines, 22 on our own shelf in Augusta, GA. The rest we source — select what you need and send one quote request, answered within one business day.

TM 9-2320-280-24P figure 329, 0 384-1 . . . . . . . . . . . . . . . . . . . . .1 Figure 419 . . . . . . . . . . . . . . . .0, sheet 1 of 2: exploded drawing with item numbers

Drawing from TM 9-2320-280-24P, approved for public release. Open it full size to zoom.

Your truck

Item	Part	Qty	On our shelf
1	Cap Hexagon Head Screw NSN 5305-00-543-2419 · P/N B1821BH038C113N SCREW,CAP,HEXAGON H 3/8-16 X 1-1/8, USBL EFF 100,000 AND ABOVE Fits: All models	1	1,168 in stock
2	Rearview Mirror Arm NSN 2540-01-314-1188 · P/N 12342131 ARM,REARVIEW MIRROR USBL EFF 100, 000 AND ABOVE Fits: All models	1	188 in stock $30–$60 eachtypical
3	Vehicular Mirror Head NSN 2540-01-314-1189 · P/N 0462 MIRROR HEAD,VEHICUL GREEN R.H USBL EFF 100,000 AND ABOVE Fits: All models	1	182 in stock $75.00our price Buy online ↗
3	Vehicular Mirror Head NSN 2540-01-314-1190 · P/N 0461 MIRROR HEAD,VEHICUL GREEN L.H USBL EFF 100,000 AND ABOVE Fits: All A0 and A1 models, plus M1121	1	89 in stock $72.00our price Buy online ↗
3	Mirror Assembly NSN 2540-01-487-3616 · P/N 0462A MIRROR ASSEMBLY,REA TAN R.H Fits: All models	1	284 in stock $72.00our price Buy online ↗
3	Rea Tan L.h. Mirror Assembly NSN 2540-01-487-3626 · P/N 1305A MIRROR ASSEMBLY,REA TAN L.H.,LOWER MOUNT ONLY Fits: All models	1	We can source it
3	Vehicul Green L.h Mirror Head NSN 2540-01-410-8794 · P/N 1351 MIRROR HEAD,VEHICUL GREEN L.H, LOWER MOUNT ONLY Fits: All models	1	21 in stock
4	Sleeve Spacer NSN 5365-01-315-3595 · P/N 12342139 SPACER,SLEEVE USBL EFF 100,000 AND ABOVE Fits: All models	2	27 in stock
5	Rearview Mirror Arm NSN 2540-01-314-2101 · P/N 12342138 ARM,REARVIEW MIRROR USBL EFF 100, 000 AND ABOVE Fits: All models	2	19 in stock $30–$60 eachtypical
6	Flat Washer NSN 5310-01-389-3455 · P/N 120393 WASHER,LOCK 5/16,USBL EFF 100,000 AND ABOVE Fits: All models	6	We can source it
7	Lock Washer NSN 5310-00-407-9566 · P/N MS35338-45 WASHER,LOCK 5/16,USBL EFF 100,000 AND ABOVE Fits: All models	4	2,036 in stock
8	Machine Bolt NSN 5306-00-225-8503 · P/N MS90725-39 BOLT,MACHINE 5/16-18 X 1-3/4, USBL EFF 100,000 Fits: All models	2	263 in stock
9	Self-Locking Hexagon Nut NSN 5310-00-814-0673 · P/N MS51943-33 NUT,SELF-LOCKING,HE 5/16-18,USBL EFF 100,000 AND ABOVE Fits: All models	2	354 in stock
10	Loop Clamp NSN 5340-01-315-3611 · P/N 12342132 CLAMP,LOOP USBL EFF 100,000 AND ABOVE Fits: All models	2	We can source it
11	Machine Bolt NSN 5306-00-225-8499 · P/N MS90725-34 BOLT,MACHINE 5/16-18 X 1.00 USBL EFF 100,000 AND ABOVE Fits: All models	2	276 in stock
12	Self-Locking Hexagon Nut NSN 5310-01-126-9404 · P/N 9422277 NUT,SELF-LOCKING,HE 3/8-16 USBL EFF 100,000 AND ABOVE Fits: All models	6	We can source it
13	Flat Washer NSN 5310-00-080-6004 · P/N MS27183-14 WASHER,FLAT 3/8,USBL EFF 100,000 AND ABOVE Fits: All models	6	1,146 in stock $7.83our price Buy online ↗
14	Locked in Stud NSN 5307-01-316-2986 · P/N 6185 STUD,LOCKED IN USBL EFF 100,000 AND ABOVE Fits: All models	2	68 in stock $45–$90 eachtypical
15	Angle Bracket NSN 5340-01-408-6460 · P/N 12343063 BRACKET,ANGLE LOWER L.H Fits: All A2 models, plus M1123	1	100 in stock
15	Angle Bracket NSN 5340-01-314-1956 · P/N 12342137 BRACKET,ANGLE LOWER L.H. USBL EFF 100,000 AND ABOVE Fits: All A0 and A1 models, plus M1121	1	14 in stock
15	Angle Bracket NSN 5340-01-316-2959 · P/N 12342136 BRACKET,ANGLE LOWER R.H. USBL EFF 100,000 AND ABOVE Fits: All models	1	79 in stock $25–$40 eachtypical
16	Flat Washer NSN 5310-01-313-3562 · P/N MS51859-20 WASHER,FLAT 3/8,USBL EFF 100,000 AND ABOVE Fits: All models	4	197 in stock
17	Angle Bracket NSN 5340-01-408-6456 · P/N 12343062 BRACKET,ANGLE UPPER L.H Fits: All A2 models, plus M1123	1	100 in stock $25–$40 eachtypical
17	Angle Bracket NSN 5340-01-314-1955 · P/N 12342135 BRACKET,ANGLE UPPER L.H.,USBL EFF 100,000 AND ABOVE Fits: All A0 and A1 models, plus M1121	1	1 in stock $25–$55 eachtypical
17	Angle Bracket NSN 5340-01-316-1507 · P/N 12342134 BRACKET,ANGLE UPPER R.H. USBL 100, 000 AND ABOVE Fits: All models	1	78 in stock
18	Machine Bolt NSN 5306-00-226-4827 · P/N B1821BH031C100N BOLT,MACHINE 5/16-18 X 1.00,USBL EFF 100,000 AND ABOVE Fits: All models	2	292 in stock

Buy the 4 in-stock parts on our store ↗

Qty is how many the assembly uses, as the manual lists it. Our price is our online store's price: Buy online opens that part on secoparts.net for card checkout. Typical is an estimate from the government catalog price and what we have charged for similar parts — not a quote. Gov't list price is the government catalog (FEDLOG) price, a public reference, not ours. "Fits" comes from the manual's usable-on codes; a line without codes applies to every model.
