HMMWV Data Plates, Surge Tank, Fan Shroud, and Cook Stove TM 9-2320-280-24P · Fig. 356

Every part in figure 356 of TM 9-2320-280-24P (HMMWV M998 series (A0, A1 and A2) repair parts), group 2210 Data Plates and Instruction Holders: 6 lines, 3 on our own shelf in Augusta, GA. The rest we source — select what you need and send one quote request, answered within one business day.

TM 9-2320-280-24P figure 356, Data Plates, Surge Tank, Fan Shroud, and Cook Stove: exploded drawing with item numbers

Drawing from TM 9-2320-280-24P, approved for public release. Open it full size to zoom.

Your truck

Item	Part	Qty	On our shelf
1	Identification Marker NSN 7690-01-209-0864 · P/N 12339065 MARKER,IDENTIFICATI SURGE TANK Fits: All models	1	243 in stock
2	Instruction Plate NSN 9905-01-248-9550 · P/N 12339055 PLATE,INSTRUCTION NO STEP Fits: All models	4	16 in stock
3	Decal NSN 7690-01-473-4550 · P/N EX4319 DECAL SERPENTINE BELT Fits: All A2 models, plus M1123	1	We can source it
4	Decal NSN 7690-01-197-5500 · P/N 12339064 DECAL FAN SHROUD Fits: All models	2	1 in stock
5	Identification Marker NSN 7690-01-188-5144 · P/N 12340909 MARKER,IDENTIFICATI GASOLINE BURNER STOVE STOWAGE Fits: M966, M966A1, M1045, M1045A1, M1046, M1046A1 and 1 more	1	We can source it $126.42 per eachgov't list price
6	Instruction Plate NSN 9905-01-248-9551 · P/N 5590177 PLATE,INSTRUCTION NO STEP Fits: All models	1	We can source it

Qty is how many the assembly uses, as the manual lists it. Our price is our online store's price: Buy online opens that part on secoparts.net for card checkout. Typical is an estimate from the government catalog price and what we have charged for similar parts — not a quote. Gov't list price is the government catalog (FEDLOG) price, a public reference, not ours. "Fits" comes from the manual's usable-on codes; a line without codes applies to every model.
