HMMWV Kit, Towed Vulcan System TM 9-2320-280-24P · Fig. 452

Every part in figure 452 of TM 9-2320-280-24P (HMMWV M998 series (A0, A1 and A2) repair parts), group 3307 Special Purpose Kits: 5 lines, 3 on our own shelf in Augusta, GA. The rest we source — select what you need and send one quote request, answered within one business day.

TM 9-2320-280-24P figure 452, Kit, Towed Vulcan System: exploded drawing with item numbers

Drawing from TM 9-2320-280-24P, approved for public release. Open it full size to zoom.

Your truck

Item	Part	Qty	On our shelf
1	Kit P/N 57K1641 KIT,CAMOUFLAGE RACK PART OF KIT P/N 57K0235 Fits: M1097	1	Ask us
2	Seat Parts Kit NSN 2540-01-185-3216 · P/N 12338105 PARTS KIT,SEAT PART OF KIT P/N 57K0235 Fits: M1097	1	32 in stock $805.00 per eachgov't list price
3	Body Vehicular Panel NSN 2510-01-246-8287 · P/N 12338119 PANEL,BODY,VEHICULA PART OF KIT P/N 57K0235 Fits: M1097	1	1 in stock $643.44 per eachgov't list price
4	Fitted Cover NSN 2540-01-316-0892 · P/N 57K0112 COVER,FITTED,VEHICU PART OF KIT P/N 57K0235 Fits: M1097	1	We can source it
5	Fitted Vehicular Cab Cover NSN 2540-01-191-0973 · P/N 12340744 COVER,FITTED,VEHICU PART OF KIT P/N 57K0235 COVER,FITTED,VEHICU( 1) 452-4 COVER,FITTED,VEHICU( 1) 452-5 KIT,CAMOUFLAGE ( 1) 452-1 PANEL,BODY,VEHICULA( 1) 452-3 PARTS KIT,SEAT ( 1) 452-2 Fits: M1097	1	15 in stock $912.00our price Buy online ↗
